New Tri-Axle 40 Tons Foot Container Chassis Flatbed Semi Trucks Trailer

New Tri-Axle 40 Tons Foot Container Chassis Flatbed Semi Trucks Trailer

Tri-Axle Flatbed Trailer

40ft Semi Trucks Trailer

Foot Container Chassis Flatbed Trailer

Place of Origin:

CHINA

Brand Name:

howo

Certification:

ISO,CCC,CE

Model Number:

380HP

Contact Us
Request A Quote
Product Details
Transmission Type:
Manual
Fuel Type:
Diesel
Condition:
Used
Horsepower:
336/375
Drive Wheel:
4
Gross Vehicle Weight:
3.06
Dimensions (l X W X H) (mm):
10329*2490*3450
Capacity (load):
15.9ton
Color:
Customized
Engine:
Weichai
Highlight:

Tri-Axle Flatbed Trailer

,

40ft Semi Trucks Trailer

,

Foot Container Chassis Flatbed Trailer

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
standard export package
Delivery Time
20 days
Payment Terms
L/C,, T/T, Western Union, MoneyGram
Supply Ability
100 unit per year
Product Description

New Tri-Axle Flatbed Trailer 40 Tons 20ft 40ft Foot Container Chassis Flatbed Semi Trucks Trailer Cheap




heavy duty Flatbed semi-trailer   is a new technology platform with higher technology content in China. During the research and development period, a large number of cutting-edge technologies have been adopted, and international top research and development teams such as Germany's MAN, BOSCH, AVL, and American Cummins have been combined to ensure the complete vehicle. High reliability and reduced failure rate. In order to create the best profit model of high speed, high efficiency, high reliability and fuel saving for users, Shaanxi Automobile fully launched the Delong F3000 high-speed version of the traction heavy truck. Performance and safety performance Shaanxi Auto Delong F3000 cab has been improved with higher technology. The latest cab sound insulation technology has been adopted to reduce the noise inside the car by 15%.



Trade Terms:

Delivery time: Wihtin 5-8 working days after receipt of down payment.

Packing : Nude packing.

Shipment: By RO-RO or Bulk vessel .

Price validity: Within 30 days.

Payment terms: T/T before shipment.

Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.

Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.



Product heavy duty Flatbed semi-trailer  Model 380Hp
Drive type left-hand drive or Right-hand Drive
Dimension Overall dimension (mm) L*W*H 10329*2490*3450
Box inside dimension (mm) L*W*H 7600*2300*1100
Bucket cubage (m 3 ) 20
Thickness of box (mm) floor 8, side 4
Wheel base (mm) 3625+1350
Overhang (front/rear, mm) 1500/1739
Wheel tread (frong/rear, mm) 2022/1830
Approach/departure angle (°) 19/26
Weight Gross vehicle weight(kg) 14600
Pay load (kg) 15930
Actual load (kg) > 15930
Overall weight (kg) 30660
Box lifting type Front hydraulic lifting
Max. speed (km/h) 75
Chassis Number of axles 3
Tire 12.00R20, radial tire
Number of tires 10+1
Cab Model HW70 standard, two seats,
air conditioner, no bed
Engine Model WD615.47
Displacement (ml) 9726
Rated power (hp/rpm) 371/2200
Emission standard Euro 2
Fuel tank capacity (L) 300
Clutch Model single, dry spring
Gear box Model HW19710
Type manual
Gears 10 forward, 2 reverse
PTO included
Steering Model ZF 8098
Type integral power steering
Front axle Model HF9 hub, 9,000 kgs
Rear axle Model HC16, 2x16,000 kgs
Braking system Type Air brake
ABS Optional


 New Tri-Axle  40 Tons  Foot Container Chassis Flatbed Semi Trucks Trailer 0New Tri-Axle  40 Tons  Foot Container Chassis Flatbed Semi Trucks Trailer 1New Tri-Axle  40 Tons  Foot Container Chassis Flatbed Semi Trucks Trailer 2New Tri-Axle  40 Tons  Foot Container Chassis Flatbed Semi Trucks Trailer 3
