3 Axles 45tons Used Truck Trailer Flatbed Trailer For 13M Container Carrier

1
MOQ
3 Axles 45tons Used Truck Trailer Flatbed Trailer For  13M Container Carrier
Features Gallery Product Description Request A Quote
Features
Specifications
Transmission Type: Manual
Fuel Type: Diesel
Condition: Used
Horsepower: 336/375
Drive Wheel: 4
Gross Vehicle Weight: 3.06
Dimensions (l X W X H) (mm): 10329*2490*3450
Capacity (load): 15.9ton
Color: Customized
Engine: Weichai
High Light:

45 tons Used Truck Flatbed Trailer

,

13M Used Truck Trailer

,

Container Carrier Used Truck Flatbed Trailer

Basic Infomation
Place of Origin: CHINA
Brand Name: howo
Certification: ISO,CCC,CE
Model Number: 380HP
Payment & Shipping Terms
Packaging Details: standard export package
Delivery Time: 20 days
Payment Terms: L/C,, T/T, Western Union, MoneyGram
Supply Ability: 100 unit per year
Product Description

3 Axles 45tons Used Truck Trailer Flatbed Trailer For 13M Container Carrier ​



The flatbed semi-trailer has no fences in the on-board part and is widely used, mainly used for medium and long-distance freight transportation.
1. The flat-panel semi-trailer walking structure is made of high-strength international steel; the whole vehicle is light in weight, and ensures its anti-torsion, anti-vibration and anti-bump ability to meet the bearing capacity of different road surfaces.
2. The frame of the series semi-trailer is a beam-through structure, and the longitudinal beam is straight or gooseneck. The height of the web is from 400mm to 550mm, the longitudinal beam is welded by automatic submerged arc welding, the frame is treated by shot peening, and the cross beam penetrates the longitudinal beam and is welded as a whole.
3. It is composed of tandem dry plate spring and suspension support, with reasonable structure, strong rigidity and strength, and is used to support load and buffer shock.

heavy duty Flatbed semi-trailer   is a new technology platform with higher technology content in China. During the research and development period, a large number of cutting-edge technologies have been adopted, and international top research and development teams such as Germany's MAN, BOSCH, AVL, and American Cummins have been combined to ensure the complete vehicle. High reliability and reduced failure rate. In order to create the best profit model of high speed, high efficiency, high reliability and fuel saving for users, Shaanxi Automobile fully launched the Delong F3000 high-speed version of the traction heavy truck. Performance and safety performance Shaanxi Auto Delong F3000 cab has been improved with higher technology. The latest cab sound insulation technology has been adopted to reduce the noise inside the car by 15%.

Product heavy duty Flatbed semi-trailer  Model 380Hp
Drive type left-hand drive or Right-hand Drive
Dimension Overall dimension (mm) L*W*H 10329*2490*3450
Box inside dimension (mm) L*W*H 7600*2300*1100
Bucket cubage (m 3 ) 20
Thickness of box (mm) floor 8, side 4
Wheel base (mm) 3625+1350
Overhang (front/rear, mm) 1500/1739
Wheel tread (frong/rear, mm) 2022/1830
Approach/departure angle (°) 19/26
Weight Gross vehicle weight(kg) 14600
Pay load (kg) 15930
Actual load (kg) > 15930
Overall weight (kg) 30660
Box lifting type Front hydraulic lifting
Max. speed (km/h) 75
Chassis Number of axles 3
Tire 12.00R20, radial tire
Number of tires 10+1
Cab Model HW70 standard, two seats,
air conditioner, no bed
Engine Model WD615.47
Displacement (ml) 9726
Rated power (hp/rpm) 371/2200
Emission standard Euro 2
Fuel tank capacity (L) 300
Clutch Model single, dry spring
Gear box Model HW19710
Type manual
Gears 10 forward, 2 reverse
PTO included
Steering Model ZF 8098
Type integral power steering
Front axle Model HF9 hub, 9,000 kgs
Rear axle Model HC16, 2x16,000 kgs
Braking system Type Air brake
ABS Optional


 3 Axles 45tons Used Truck Trailer Flatbed Trailer For  13M Container Carrier 03 Axles 45tons Used Truck Trailer Flatbed Trailer For  13M Container Carrier 13 Axles 45tons Used Truck Trailer Flatbed Trailer For  13M Container Carrier 23 Axles 45tons Used Truck Trailer Flatbed Trailer For  13M Container Carrier 33 Axles 45tons Used Truck Trailer Flatbed Trailer For  13M Container Carrier 4
