| VEHICLE SPECIFICATION | DESCRIPTION | |
| Truck Model | ZZ4257S3241W | |
| Truck Type | 6x4 | |
| Driving Position | Left Hand Driving | |
| Fuel tanker capacity(L) | 400L | |
| Color | Optional | |
| Chassis & Add Components | ||
| Frame Details | High-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sub frame, all cold riveted cross members. | |
| Dimension(Lx W xH)(unloaded)(mm) | 6800*2560*3000 | |
| Wheel base (mm) | 3225+1350 | |
| Engine | ||
| Model | WD615.47 | |
| Power | 371HP | |
| Emission | EURO II | |
| Displacement(L) | 9.726 | |
| Type | water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection | |
| Kind of Fuel | Diesel | |
| Clutch & Gear Box System | ||
| Clutch | SINOTRUKΦ430mm diaphragm spring clutch | |
| Gear Box | HW19710 | |
| Axles | ||
| Front Axle Model | HF7 axle | |
| Rear Axle | ST16 axle | |
| Electrical System | ||
| Battery | 2X12V/165Ah | |
| Alternator | 28V-1500w | |
| Starter | 7.5Kw/24V | |
| Brake System | ||
| Service brake | Dual circuit compressed air brake | |
| Parking brake | spring energy, compressed air operating on rear wheels | |
| Auxiliary brake | Engine exhaust brake | |
| Steering system | ||
| Model | Standard | |
| Type | hydraulic steering with power assistance | |
| Wheels & Tyres | ||
| Type | 12R22.5 tubeless tire | |
| Brand | Standard Brand | |
| Quantity | 10+1 spare | |
| Kin pin | 50mm/90mm | |
| Cabin | ||
| Type | HW76 Standard cabin | |
| Single sleeper with air conditioner, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers | ||
|
Special request: 1: High steel bumper 2. 2kg fire extinguisher 3.backup buzzer
|
||
