HOWO 8X4 371HP BRAND-NEW DUMPER TRUCK
SPECIFICATION
| Truck Model | ZZ3317N3567 | |||
| Truck Brand | SINOTRUK—HOWO | |||
| Dimension(Lx W xH)(unloaded)(mm) | 10245*2600*3450 | |||
| Driving Type | Left Hand Driving | |||
| Cargo body size (L*W*H, mm) | 7300*2300*1500mm 25.185m3 bottom:8mm,side:6mm | |||
| Lifting Cylinder | China Brand | |||
| Lifting Type | Front side Lifting | |||
| Approaching angle/Departure angle(°) | 19/21 | |||
| Overhang(front/rear) (mm) | 1500/2095 | |||
| Wheel base (mm) | 1800+3500+1350 | |||
| Curb weight(kg) | 15390 | |||
| Persons in cab(persons) | 2 | |||
| Gross vehicle weight(kg) | 31000 | |||
| Max speed(km/h)(km/h) | 75-80 | |||
| Engine Model |
WD615.47 4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and inter-cooling |
|||
| Fuel type | Diesel | |||
| Horse Power, max(kw/rpm) | 371HP | |||
| Emission | EURO II | |||
| Fuel tanker capacity (L) | Standard | |||
| Transmission Model | HW19710 10 forwards and 2 reverse | |||
| Steering Model | Mechanical transmission with hydraulic assistance Steering gear recalculating ball type. | |||
| Clutch | single disc, dry type, diaphragm spring ;φ430 | |||
| Service brake | Dual circuit compressed air brake | |||
| Parking brake | spring energy, compressed air operating on rear wheels | |||
| Auxiliary brake | The engine exhaust brake (EVB) | |||
| Front axle | HF9 Steering with double T-cross section beam | |||
| Rear axle | HC16 Casting axle housing, central double reduction with differential locks between axles and wheels | |||
| Color | White, Red, Yellow. according to the customer | |||
| Tire |
12.00R20 steel wire tire NO.12+1 Pieces |
|||
| Electrical system | Battery | 2X12V/180Ah | ||
| Alternator | 28V-1500kw | |||
| Starter | 7.5Kw/24V | |||
| Cab | HW76 cab (single sleeper, with air-condition),safety belt for drive and co-drive, two seats, air condition, English VDO panel, driver seats with air suspension. With top warning lights two pcs. | |||
ZHENGZHOU COOPER INDUSTRY CO., LTD., is one professional exporter of both brand new and used commercial vehicles and heavy equipment , as well as relevant spare parts in China.
For bus, like Coach Bus, City Bus, School Bus, coaster bus, the brands includes YUTONG, HIGER, KINGLONG, GOLDEN DRAGON, ZHONGTONG, TOYOTA, etc. For trucks, like dump truck, tractor truck, special purpose trucks, brands includes DONGFENG, SINOTRUCK HOWO, SHACMAN, BEIBEN, HUALING, etc.
With very good relationship with the Chinese main bus and truck manufacturers, and the professional team on sourcing of used/second hand bus & trucks and on export business, ZHENGZHOU COOPER INDUSTY CO., LTD. has grown quickly to a professional and famous exporter in commercial vehicles and heavy equipment, especially for the used/second units.
Looking to the future, ZHENGZHOU COOPER INDUSTY CO., LTD. will enhance core competitiveness of enterprises as a goal, enhance more professional skills to "MEET EVERY CUSTOMER’S REQUIREMENT" !
