15 Cubic Metre 18 Ton Dongfeng 4x2 6x4 Water Tank Fire Truck Sprinkler Sale

Product Details

Name:

15 Cubic Metre 18 Ton Dongfeng 4x2 6x4 Water Tank Fire Truck Sprinkler Sale

Power:

210HP 260HP

Standard:

Euro3

Brand:

Dongfeng Howo Shacman FAW

Capacity:

5 10 15 18 20 Tons

Shipping:

Within 1 Month

Highlight:

18T Water Tank Fire Truck

260HP Water Tank Fire Truck

30000L Water Tank Fire Truck

Payment & Shipping Terms

Minimum Order Quantity

1Unit

Packaging Details

Nude Packing

Delivery Time

20-30 days

Payment Terms

T/T, Western Union, L/C

Supply Ability

50unit per month

Crane Truck Mounted Lifting Weight 4 Tons Dayun 4*2 Single And Half Cab Grabbing Wood 200hp

Get Best Price

Concrete Pump Truck 37 Meters Zoomlion 6*4 Sinotruk Sitrak Chassis Five-Section Boom For Flexibility

Get Best Price

Used Water Tanker Truck 20000 Liters Shacman F3000 Chassis 6*4 Euro 3 Emission LHD ＆ RHD

Get Best Price

Howo ZZ5187 Freight Refrigerated Truck Diesel 8-Speed 220hp 4X2 6.8m Deflector Row Half Cab White Body Three-Door

Get Best Price

+8619949131219

sales008@zzcooper.com

86-371-61656353

Contact Now

Product Description

15 Cubic Metre 18 Ton Dongfeng 4x2 6x4 Water Tank Fire Truck Sprinkler Sale
* Water tank volume: from 2000liters to 30000liters, and 30000~50000liters water tank semi trailer
* Fog cannon capacity: 25~30m, 40m, 50m, 60m, 70m, 80m, 100m, 120m, etc
* Function: dust suppression, cleaning road surface, water spraying dry road surface, transport water, green gardening, emergency fire fighting, etc
* All watering valves or discharge valves can be automatically controlled in driving cabin
* Chasiss brand optional: HOWO, Hongyan, DONGFENG, JMC, FOTON, SHACMAN, JAC, JAPAN BRAND, LIUQI CHENGLONG, etc

Product Name	Water tank truck
Driving Type	Left hand drive ( RHD is optional)
Weights
GVW(kg)	6000, 15000, 25000, 31000
Rated payload weight(kg)	3000L-30000L 3CBM-30CBM 3 tons to 30 tons
Curb weight(kg)	9005
Dimensions
Wheelbase(mm)	4325+1350 3300, 3800, 4500, 5100mm is optional
Overall Dimension(mm)	9800×2495×3130
Box dimension	3-30 CBM 3000L -30000L
Max speed(km/h)	98
Engine
Engine model	WP10.290 (120hp, 190hp, 266hp, 340hp, 380hp, 420hpHP)
Engine type	4 stroke water-cooled,water-cooling.
No. of cylinders	straight-6 cylinders
Displacement(L)/Power(km)	6.494/162
Max. torque (kw)	800N.m
Drive Line
Transmission	7DS100,7 forwards,1 reverse gear,manual operation
Steering	With power steering
Brake system	Air brake
Cab
Air container	Have
Standard configuration	L cab,sound, and so on
Axle
Front axle	5 tons
Rear axle	AK153 tons
Tire specification
Tire specification	10.00R20 standard tire,10 tires+1 spare tire
Specification fuctionof water truck
Tanker shape	Ellipse water tanker
Tanker material	Q235,carbon steel
Introduction	1. Suction≥7m Sprinkler width≥14m Range≥28m
	2. with front spout, back spill and side spout function
	3. with the working platform at the back, wich can be installed green high-pressure water spray gun.(The spray gun shape can be adjustable: heavy rain, moderate rain, drizzling rain or haze.)
	4. Provide the best high-power sprinkle pumps quality of the national,And with fire coupling, self-flow add self- priming function.
Sprinkling area(m)	»14m	Vertical suction range (m)	»7m
Watering pressure	250-450Mpa	Pump style	Self-priming centrifugal pump
Manhole	Manway access hole on top of tank;1 units DN500mm manhole
Front spray function	Front spray bar with fan sprayer on both sides, spray range: »28m
Manwalk way	With skid resistance manwalk way on top of tank
Horse reels	Two 75 ft hose reels at each side of the truck
Water pump	Water pump model: CLW80QZF-60/90N
	Water pump flow rate(L/m): 60m3/h
	Head of delivery(m): 90m
	Self-priming function(min/4m):1.5
	Efficiency(%):95%
