Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2

China Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2 supplier
Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2 supplier Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2 supplier

Large Image :  Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2

Product Details:

Place of Origin: CHINA
Brand Name: CAT
Certification: CE
Model Number: 307E2

Payment & Shipping Terms:

Minimum Order Quantity: 1Unit
Packaging Details: Nude Packing
Delivery Time: 10-20 Workdays
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10Unit/Month
Contact Now
Detailed Product Description
Name: Used Excavator Brand: Caterpillar
Years: 2018 Operating Weight: 7270kg
Condition: Used Name: Construction Machines

Used Excavator CAT 307E2 Small hydraulic pressure 2008 Years Second Construction Machine



Benefits:

QUALITY

The standard tail swing design incorporates a counterweight that extends further back on the machine for greater stability. The standard tail swing paired with a fixed boom on the 307E2 provides superior reach and lift. The operator environment includes a high quality suspension seat, easy to adjust armrests and 100% pilot controls which offer consistent and long-lasting controllability.

EFFICIENCY

High Definition Hydraulic System provides a load sensing and flow sharing capability leading to operational precision, efficient performance and greater controllability. Power on Demand provides optimal efficiency and performance the moment you need it. This automatic system ensures fuel efficiency through appropriate engine rating to meet all operational needs as required.

VERSATILITY

Broad range of Cat Work Tools make the Cat Mini Excavator a versatile machine, able to meet the requirements of any job site. 180 degrees of bucket rotation provides greater material retention during truck loading and easier flat wall digging without having to reposition the machine.

PERFORMANCE

Front shovel bucket orientation provides the operator with more ways to get the job done faster. COMPASS Control Panel is a standard feature that allows the operator to easily adjust auxiliary flows to achieve the optimal work tool performance, activate auto idle for improved fuel efficiency and utilize the security system to ensure protection of valuable assets with the simple touch of a button. The Site Reference System included in the COMPASS monitor provides output from pitch and roll sensors to aid in grading and level trenching. This impacts accuracy and productivity for job site finishing. Rearview camera improves operator productivity and efficiency through increased visibility, making work easier to complete.

SERVICEABILITY

Convenient service and maintenance requirements include ease of access to daily check points, 500 hour engine oil and filter change period, 500 hour grease interval on front implement, S·O·SSM oil sampling valve and overall long term durability.

QUALITY

All Cat Mini Excavators from 3.5 metric tons to 8 metric tons are ROPS, TOPS and Top Guard Level II certified and include the Cat Interlock (hydraulic lockout) System, a certified accumulator which allows for auxiliary pressure to be released, making connecting and disconnecting work tools safer and easier, and a travel alarm. All of these safety features are standard on the E2 model lineup (travel alarm optional in Europe).

TWICE THE COVERAGE ON COMPACT MACHINES

Caterpillar is introducing a new, 2-year machine standard warranty for Cat® Skid Steer Loaders, Compact Track Loaders, Multi Terrain Loaders and Mini Excavators in the U.S. and Canada.

Specifications:

OVERVIEW

The Cat® 307E2 Mini Hydraulic Excavator delivers high performance, durability and versatility in a standard tail swing design to help you work in a variety of applications.

ENGINE

UNITS:

Engine Model Cat® C2.4 Turbo
Net Power 37.7 kW
Bore 87.0 mm
Displacement 2.4 l
Gross Power - ISO 14396 39.6 kW
Note Meets U.S. EPA Tier 4 Final and EU Stage IIIB emission standards.
Rated Net Power - 2,200 rpm - ISO 9249/EEC 80/1269 37.7 kW
Stroke 102.4 mm

WEIGHTS

Operating Weight 7270.0 kg
Operating Weight - With Cab 7270.0 kg
Note (1) Weight with steel tracks with rubber pads, bucket, operator (75 kg/165 lb), full fuel and auxiliary lines.
Note (2) Weight varies depending on machine configuration.

TRAVEL SYSTEM

Ground Pressure 33.9 kPa
Gradeability - Maximum 20°
Maximum Traction Force - High Speed 33.8 kN
Maximum Traction Force - Low Speed 59.3 kN
Travel Speed - High 5.1 km/h
Travel Speed - Low 3.2 km/h
Note (1) Each track is driven by one independent 2-speed motor.
Note (2) Drive modules are integrated into the roller frame for total protection.
Note (3) Straight line travel when tracking and operating the front linkage simultaneously.

HYDRAULIC SYSTEM

Auxiliary Circuit - Primary (280 bar/4,061 psi) 128.0 l/min
Auxiliary Circuit - Secondary (280 bar/4,061 psi) 33.0 l/min
Digging Force - Bucket 50.6 kN
Digging Force - Stick - Standard 37.1 kN
Note Load sensing hydraulics with variable displacement piston pump.
Operating Pressure - Equipment 28000.0 kPa
Operating Pressure - Swing 28000.0 kPa
Operating Pressure - Travel 28000.0 kPa
Pump Flow at 2,400 rpm 154.0 l/min

SWING SYSTEM

Machine Swing Speed 10.2 r/min
Note Automatic swing break, spring applied, hydraulic release.

BLADE

Width 2300.0 mm
Height 445.0 mm
Dig Depth 390.0 mm
Lift Height 350.0 mm

SERVICE REFILL CAPACITIES

Cooling System 14.0 l
Engine Oil 11.0 l
Hydraulic Tank 51.0 l
Fuel Tank 135.0 l
Hydraulic System 78.0 l

OPERATING SPECIFICATIONS

Machine Overhang 358.0 mm
Stick Length - Standard 1670.0 mm

CAB

Average Exterior Sound Pressure 98 dB(A) ISO 6395 - Dynamic Test

DIMENSIONS - STANDARD STICK

Boom Height - Shipping Position 2630.0 mm
Boom In Reach 1690.0 mm
Dig Depth 4070.0 mm
Maximum Blade Depth 350.0 mm
Maximum Blade Height 390.0 mm
Maximum Dig Height 7240.0 mm
Maximum Dump Clearance 5190.0 mm
Maximum Reach 6300.0 mm
Maximum Reach - Ground Level 6160.0 mm
O/A Shipping Height 2630.0 mm
O/A Shipping Length 6080.0 mm
O/A Track Width 2200.0 mm
O/A Undercarriage Length 2760.0 mm
Swing Bearing - Height 775.0 mm
Tail Swing - Standard Counterweight 1750.0 mm
Track Belt/Shoe Width 450.0 mm
Vertical Wall 3630.0 mm

UNDERCARRIAGE

Number of Carrier Rollers 1 per side
Number of Track Rollers 5 per side
Track Roller Type Center flange
Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2Small Hydraulic Pressure Construction Machines 2008 Years Used Excavator CAT 307E2
