Place of Origin:
China
Brand Name:
HOWO
Certification:
ISO CE CCC
Model Number:
ZZ3257N3447A
Specification
| VEHICLE SPECIFICATION | DESCRIPTION | |
| Type of Vehicle | ZZ3257N3447A | |
| Truck Type | 6x4 | |
| Driving Position | Left hand Driving | |
| Truck weight | 8680kg | |
| G.V.W | 25,000kg | |
| Max speed(km/h) | 75 | |
| Color | Red | |
| Chassis & Add Components | ||
| Frame Details | High-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sub frame, all cold riveted cross members. | |
| Dimension(Lx W xH)(unloaded)(mm) | 7125*2496*3600 | |
| Cargo box: | 5200*2300*1400mm(bottom: 8mm, side: 6mm) | |
| Approaching angle/Departure angle(°) | 16/70 | |
| Overhang(front/rear) (mm) | 1500/725 | |
| Wheel base (mm) | 3425+1350 | |
| Engine | ||
| Model | WD615.69 | |
| Power | 336HP | |
| Emission | EURO III | |
| Displacement(L) | 9.726 | |
| Type | water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection | |
| Kind of Fuel | Diesel | |
| Clutch & Gear Box System | ||
| Clutch | SINOTRUKΦ430mm diaphragm spring clutch | |
| Gear Box | HW19710 10 forwards and 2 reverse | |
| Axles | ||
| Front Axle Model | HF9 axle | |
| Rear Axle | HC16 axle | |
| Electrical System | ||
| Battery | 2X12V/165Ah | |
| Alternator | 28V-1500w | |
| Starter | 7.5Kw/24V | |
| Brake System | ||
| Service brake | Dual circuit compressed air brake | |
| Parking brake | spring energy, compressed air operating on rear wheels | |
| Auxiliary brake | Engine exhaust brake | |
| Steering system | ||
| Model | 8118 | |
| Type | hydraulic steering with power assistance | |
| Wheels & Tyres | ||
| Type | 11.00R20 | |
| Brand | Common Brand | |
| Quantity | 10+1 spare | |
| Kin pin | 90mm | |
| Cabin | ||
| Type | HW76 New cabin | |
| Double sleeper, with air conditioner, all-steel forward control,55ºhydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers | ||
Trade Terms:
Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
