Place of Origin:
China
Brand Name:
Howo
Certification:
ISO CE CCC
Model Number:
ZZ3257N4347C
| Specification | |||
| Item | HOWO 8X4 Truck | ||
| Chassis model | ZZ3257N4347C | ||
| Driving type | Left hand drive (LHD) | ||
| Engine | Model | SINOTRUK brand, MC11.36-30, 336hp, Euro III, Diesel. | |
| Type |
Six cylinders inline, water cooling, 4 stroke, supercharge inter cooler |
||
| Fuel tanker(L) | 400 | ||
| Rated Power (kw/rpm) | 268/2400 | ||
| Maximum Torque (Nm) | 1160N.m | ||
| Maximum Torque speed | 1600RPM | ||
| Compression ratio | 17:1 | ||
| Bore X Stroke | 126x130mm | ||
| Displacement | 10.518L | ||
| Cabin |
HW76, plat-roof cab, one sleeper (berth), Air-conditioner, MP3, safety belts, curtain. Adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. |
||
| Transmission | HW197, 12 F and 2 R, manual. | ||
| Front Axles | HF7, 7T | ||
| Rear Axles | MCY13Q, 13TX2, drum brake. Speed ratio: 4.11. | ||
| Steering | ZF8118 steering gear, ZF Steering pump, power steering with hydraulic system. | ||
| Brake system | Service brake: dual circuit compressed air brake | ||
|
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels |
|||
| Auxiliary brake: engine exhaust brake | |||
| Electric system | Operating voltage: 24 V, negative grounded | ||
| Starter: 24 V, 5.4 Kw | |||
| Alternator: 3-phase, 28 V, 1500 W | |||
| Batteries: 2 x 12 V, 165 Ah | |||
| Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | |||
| Tyre | 12.00-2 | ||
| Fuel tank | L volume | ||
| Size | Overall Dimensions | 10675×2496×3050mm | |
| Wheelbase | 1950+4625+1350mm | ||
| Cargo Box | 8200*2300*970mm | ||
Trade Terms:
Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
