Product Details:

Place of Origin: CHINA
Brand Name: SANY
Certification: ISO/CCC
Model Number: SYM5253GJB1E

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: NUDE PACKING
Delivery Time: 5-8 WORK DAYS AFTER PAYMENT
Payment Terms: T/T
Supply Ability: 20 UNITS PER MONTH
Contact Now
Detailed Product Description
Condition: Used Year: 2015
Chassis Model: SYM1255T1E Overall Dimensions: 9450x2490x3960mm
Front/rear Wheel Track: 2048/1860/1860mm Engine: WP10.336E53
Emission: Euro V Rated Power: 336hp,rated Power Speed 1900rpm
Drive Form: 6X4 Max.torque: 1550N.m



Second hand Concrete Mixer Truck SANY with 6*4 drive mode and Euro V Emission,12m3 in 2015 could be used in kinds of constructions.




Vehicle parameters
Vehicle Model SYM5253GJB1E Vehicle Brand SANY
Overall dimensions 9450x2490x3960mm Curb weight 15000kg
Loading capacity 12m3



Chassis parameters
Chassis model SYM1255T1E Chassis brand SANY
Overall dimensions 9450x2490x3960mm Wheel base 3775+1400mm
Front/rear wheel track 2048/1860/1860mm Front/rear suspension 1480/2900mm
Approach/departure angle 17/17° Maximum speed 90km/h
Chassis Manufacturer SANY
Cab Configuration F3000 flat roof heating cab, main seat hydraulic seat, four-point hydraulic suspension cab, electronically controlled automatic constant temperature air conditioning, single-bed, 14 rear-view mirrors, manual window-shaking machine, manual overturn,F3000 cooling system, domestic left steering machine,180Ah battery, SHACMAN logo, all Russian logo, remote throttle control
Color White,other color is optional
Engine Model WP10.336E53
Emission Euro V
Type 4 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, exhaust valve brake, direct injection diesel engine
Rated power 336hp,rated power speed 1900rpm
Displacement 9726ml
Max.torque 1550N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co., Ltd.
Tire Size 12.00R20 steel wire tire
Number 10 nos
Clutch Eaton φ430 diaphragm clutch
Fuel tank 380L aluminium alloy
Front axle MAN, 7.5 tons disc type
Rear axle MAN,16 tons casting bridge,main reduction ratio 5.262
Drive form 6X4
Rated voltage 24V,DC
Transmissions FAST 12JSD160TA,12 speed forward 2 reverse.
Steering device Power assisted steering,steering machine
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above,please take the actual product as the standard




Concrete mixer truck structure parameters
Mixing capacity(m³) 12 Color and Logo Optional
Feeding speed (m³/min) ≥8 Discharge speed(m³/min) ≥5
Discharge residual rate ≤0.5% Slump scope(mm) 50-210
Water tank capacity(L) 300 Water pressure(Mpa) 0.35-0.38
Tank material 5mm alloy steel Tank front head 8mm alloy steel
Reducer ZF3301 Hydraulic motor Germany REXROTH
Hydraulic pump Germany REXROTH Radiator KAIPENG
Standard configuration chassis,sub frame,mixer tank,reducer, hydraulic pump,hydraulic motor, radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device.
8m3 Germany ZF3301 reducer,Germany REXROTH hydraulic pump,Germany REXROTH hydraulic motor,KAIPENG radiator,mixer tank(main tank 5mm alloy steel wear resistant material,front tank head 8mm alloy steel wear resistant material)
Selective configuration

Emergency high pressure oil hose(4 pieces),12m emergency oil hose(Italy),water cannon,large tool box,electric water supplying system.
Germany ZF/Italy PMP reducer, Italy PMP/Italy MESSORI/America EATON/America SAUER hydraulic pump, hydraulic motor.





Trade Terms:

Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.
