ZOOMLION-HOWO Used Concrete Mixer Truck Euro III Emission 11005x2496x3900mm
1 UNIT
MOQ
Negotiable
Price
ZOOMLION-HOWO Used Concrete Mixer Truck Euro III Emission 11005x2496x3900mm
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: ZOOMLION
Certification: ISO/CCC
Model Number: ZLJ5251GJBH
High Light:

second hand cement mixer

,

second hand concrete mixer trucks

Payment & Shipping Terms
Packaging Details: NUDE PACKING
Delivery Time: 5-8 WORK DAYS AFTER PAYMENT
Payment Terms: T/T
Supply Ability: 20 UNITS PER MONTH
Specifications
Condition: Second Hand
Year: 2012
Emission: Euro III
Engine: D10.34-40
Steering Wheel: Left Hand Drive
Rated Power: 340hp
Drive Form: 6X4
Chassis Model: ZZ1257N3847D1
Overall Dimensions: 11005x2496x3900mm
Loading Capacity: 10m3
Product Description




2012 Year Used 340hp ZOOMLION-HOWO Concrete Mixer Truck with Euro III Emission and 6X4 Drive form could be used in kinds of construction.



Vehicle parameters
Vehicle Model ZLJ5251GJBH Vehicle Brand ZOOMLION
Overall dimensions 11005x2496x3900mm Curb weight 15000kg
Loading capacity 10m3



Chassis parameters
Chassis model ZZ1257N3847D1 Chassis brand HOWO
Overall dimensions 11005x2496x3900mm Wheel base 3825+1350mm
Front/rear wheel track 2022/1830/1830mm Front/rear suspension 1525/2485mm
Approach/departure angle 16/16° Maximum speed 77km/h
Chassis Manufacturer SINOTRUK
Cab Configuration F3000 flat roof heating cab, main seat hydraulic seat, four-point hydraulic suspension cab, electronically controlled automatic constant temperature air conditioning, single-bed, 14 rear-view mirrors, manual window-shaking machine, manual overturn,F3000 cooling system, domestic left steering machine,180Ah battery, SHACMAN logo, all Russian logo, remote throttle control
Color White,other color is optional
Engine Model D10.34-40
Emission Euro iii
Type 4 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling, exhaust valve brake, direct injection diesel engine
Rated power 340hp,rated power speed 1900rpm
Displacement 9726ml
Max.torque 1550N.m
Bore x stroke 126x130mm
Manufacturer Weichai Power Co., Ltd.
Tire Size 12.00R20 steel wire tire
Number 10 nos
Clutch Eaton φ430 diaphragm clutch
Fuel tank 380L aluminium alloy
Front axle MAN, 7.5 tons disc type
Rear axle MAN,16 tons casting bridge,main reduction ratio 5.262
Drive form 6X4
Rated voltage 24V,DC
Transmissions FAST 12JSD160TA,12 speed forward 2 reverse.
Steering device Power assisted steering,steering machine
Steering wheel Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above,please take the actual product as the standard



Concrete mixer truck structure parameters
Mixing capacity(m³) 10 Color and Logo Optional
Feeding speed (m³/min) ≥8 Discharge speed(m³/min) ≥5
Discharge residual rate ≤0.5% Slump scope(mm) 50-210
Water tank capacity(L) 450L Water pressure(Mpa) 0.35-0.38
Tank material 5mm alloy steel Tank front head 8mm alloy steel
Reducer ZF3301 Hydraulic motor Germany REXROTH
Hydraulic pump Germany REXROTH Radiator KAIPENG
Standard configuration chassis,sub frame,mixer tank,reducer, hydraulic pump,hydraulic motor, radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device.
8m3 Germany ZF3301 reducer,Germany REXROTH hydraulic pump,Germany REXROTH hydraulic motor,KAIPENG radiator,mixer tank(main tank 5mm alloy steel wear resistant material,front tank head 8mm alloy steel wear resistant material)
Selective configuration

Emergency high pressure oil hose(4 pieces),12m emergency oil hose(Italy),water cannon,large tool box,electric water supplying system.
Germany ZF/Italy PMP reducer, Italy PMP/Italy MESSORI/America EATON/America SAUER hydraulic pump, hydraulic motor.
