Dongfeng Used Dump Truck 2013 Year Made Euro 3 Emission Standard For Mining

China Dongfeng Used Dump Truck 2013 Year Made Euro 3 Emission Standard For Mining supplier
Dongfeng Used Dump Truck 2013 Year Made Euro 3 Emission Standard For Mining supplier Dongfeng Used Dump Truck 2013 Year Made Euro 3 Emission Standard For Mining supplier Dongfeng Used Dump Truck 2013 Year Made Euro 3 Emission Standard For Mining supplier

Large Image :  Dongfeng Used Dump Truck 2013 Year Made Euro 3 Emission Standard For Mining

Product Details:

Place of Origin: China
Brand Name: Dongfeng
Certification: ISO, CCC, CE
Model Number: CT870 CT890

Payment & Shipping Terms:

Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: Nude packing
Delivery Time: 5- 8 working days after receipt of payment
Payment Terms: T/T
Supply Ability: 50 units per month
Contact Now
Detailed Product Description
Driving Mode: 6×4 Condition: Used
Curb Weight(kg): 25200/27000 Rate Weight(kg): 45000/53000
G.V.W(kg): 70000/80000 Max Gradeability (%): 36
App/Dep(°): 27.5/45 Emission Standard: Euro III/EuroII
Max Speed(km/h): 60/45 Max Inclination Angle(°): 48±2





Used Dongfeng Mining Dump Truck with 6×4 Dirve Mode and euro 3 Emission standard in 2013 year could be used in kinds of constructions.







Specifications of Dongfeng Truck
Truck Model CT870 CT890
Driving Mode 6×4 6×4
Curb Weight(kg) 25200 27000
Rate Weight(kg) 45000 53000
G.V.W(kg) 70000 80000
Overall Dimension(mm)   Length 8680 8850
    Width 3150,3200 3350
    Height 3750 3800
Min Clearance(mm) 333 350
Min Turning Diameter(m) 11.5 12
Max Gradeability (%) 36 35
App/Dep(°) 27.5/45 27.5/45
Wheel base(mm) 3560+1520 3650+1580
Tread(F/R)(mm) 2550/2236 2731/2550
Engine Model WP12NG380 WD12.375 WD12.420/BF6M1015C
Engine Displacement(L) 11.596 11.596 11.596
Rated Power(kW/PS) 280 276 309
Max Torque/Speed(N.r/min) 1500/(1400-1600) 1500/ 1750/1400-1600
(1300-1500)
Gear Box Model 7DS180 4300ORS 7DS180/45000ORS
Front Alex Loading Weight(Kg) 14000 16000
Front Alex Loading Weight(Kg) 56000 64000
Emission Standard Euro III EroII EroII
Frame(mm) 320*90*(10+8) 320*120*(10+10)
Brake System Double Circuit, Hub Brake Double Circuit, Hub Brake
Electronics System 24V 24V
Tank Volume(L) 450 350 350 350
Tyre Specification 13.00-25 14.00-25
Cargo Dimension (mm) 5600 5600
  Width   2850,2900,3000 3100,3200
  1500,1600/1680 1600,1700
Lifting Mode Front Lifting Front Lifting
Max Inclination Angle(°) 48±2 48±2
Driving Wheel Diameter(mm) 635 690
Max Speed(km/h) 60 45
Min Speed(km/h) 2 2
Carriage Lifting Time(s) ≤30 ≤30
Carriage Down Time(s) ≤18 ≤18
Braking Distance(V=30km/h) ≤23.27m ≤23.27m







Trade Terms:

Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.

Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.

Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.
