Place of Origin:
China
Brand Name:
Howo
Certification:
ISO, CCC, CE
Model Number:
ZZ4255V3246
HYUNDAI Second hand Trailer Truck 440hp with Euro V Emission Standard and 6*4 drive mode in 2016 year could be used in kinds of constructions.
| VEHICLE SPECIFICATION | DESCRIPTION | |
| Truck Model | ZZ4255V3246 | |
| Type of Vehicle | TRACTOR TRUCK | |
| Truck Type | 6x4 | |
| Driving Position | Left hand Driving | |
| Fuel tanker capacity(L) | 400L | |
| The Total Mass | 50,000kg | |
| Dead Weight | 9210 | |
| Max speed(km/h) | 102 | |
| Color | Optional | |
| Chassis & Add Components | ||
| Frame Details | High-Strength U-profile ladder frame with section of 300*90*8mm and reinforced sub frame, all cold riveted cross members. | |
| Dimension(Lx W xH)(unloaded)(mm) | 6900*2560*3880 | |
| Approaching angle/Departure angle(°) | 20/50 | |
| Overhang(front/rear) (mm) | 1550/725 | |
| Wheel base (mm) | 3225+1350 | |
| Engine | ||
| Model | D12.42 | |
| Power | 420HP | |
| Emission | EURO III | |
| Displacement(L) | 11.726 | |
| Type | water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection | |
| Kind of Fuel | Diesel | |
| Clutch & Gear Box System | ||
| Clutch | SINOTRUKΦ430mm diaphragm spring clutch | |
| Gear Box |
HW19710 10 forwards and 2 reverse |
|
| Axles | ||
| Front Axle Model | HF153 axle | |
| Rear Axle | H457 axle | |
| Electrical System | ||
| Battery | 2X12V/165Ah | |
| Alternator | 28V-1500w | |
| Starter | 7.5Kw/24V | |
| Brake System | ||
| Service brake | Dual circuit compressed air brake | |
| Parking brake | spring energy, compressed air operating on rear wheels | |
| Auxiliary brake | Engine exhaust brake | |
| Steering system | ||
| Model | D50 | |
| Type | hydraulic steering with power assistance | |
| Wheels & Tyres | ||
| Type | 12R22.5 | |
| Brand | Common Brand | |
| Quantity | 10+1 spare | |
| Kin pin | 50mm or 90mm | |
| Cabin | ||
| Type | H18 Standard cabin | |
| Double sleeper with air conditioner, | ||
Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.
