Brand: SINOTRUK HOWO
Driving type: 6X4
Cab: HW76, 2 seats, with A/C
Engine: 371hp
Transmission: HW19710, 10 forward and 2 reverse
Front axle: HF9
Driving axle: HC16
Tire: 12.00R20
Lifting system: Front lifting
Model Year: From 2009 to 2014
Emission Standard: Euro2
Color: Orange or Optional
Specifications of Used Truck
Product | HOWO 6x4 Used Dump Truck | Model | ZZ3257N3647B | |
Drive type | 6x4, left-hand drive or Right-hand Drive | |||
Dimension | Overall dimension (mm) L*W*H | 8214*2496*3386 | ||
Box inside dimension (mm) L*W*H | 5600*2300*1500 | |||
Bucket cubage (m 3 ) | 20 | |||
Thickness of box (mm) | floor 8, side 4 | |||
Wheel base (mm) | 3625+1350 | |||
Overhang (front/rear, mm) | 1500/1739 | |||
Wheel tread (frong/rear, mm) | 2022/1830 | |||
Approach/departure angle (°) | 19/26 | |||
Weight | Gross vehicle weight(kg) | 12,290 | ||
Pay load (kg) | 12,580 | |||
Actual load (kg) | > 23000 | |||
Overall weight (kg) | 25,000 | |||
Box lifting type | Front hydraulic lifting | |||
Max. speed (km/h) | 75 | |||
Chassis | Number of axles | 3 | ||
Tire | 12.00R20, radial tire | |||
Number of tires | 10+1 | |||
Cab | Model | HW70 standard, two seats, air conditioner, no bed |
||
Engine | Model | WD615.47 | ||
Displacement (ml) | 9726 | |||
Rated power (hp/rpm) | 371/2200 | |||
Emission standard | Euro 2 | |||
Fuel tank capacity (L) | 300 | |||
Clutch | Model | single, dry spring | ||
Gear box | Model | HW19710 | ||
Type | manual | |||
Gears | 10 forward, 2 reverse | |||
PTO | included | |||
Steering | Model | ZF 8098 | ||
Type | integral power steering | |||
Front axle | Model | HF9 hub, 9,000 kgs | ||
Rear axle | Model | HC16, 2x16,000 kgs | ||
Braking system | Type | Air brake | ||
ABS | Optional |
The Detection Line of Used Truck
Our Advantage:
1. Variety of products, including all kinds of light trucks, tractors, heavy duty trucks, trailers and special vehicles.
2. High quality and competitive price, technology absorbed from the top companies in the world
3. Quick response to your inquiry, we have special sales team for different markets in Asia, Africa, Europe, America,ETC
4. Flexible payment terms,we can accept T/T,L/C and installment.
5. Rich experience and strong production capacity, 60 years experience and 50000 units annual output.
Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
