| Model | ZZ5257GJBN3247C (8290) | |
| Whole Vehicle Performance & Parameters | Chassis | HOWO |
| Curb Weight (Kg) | 13500 | |
| Total Vehicle Weight (Kg) | 25000 | |
| Outline Dimension(L*B*H) (mm) | 8715*2496*3800 | |
| Wheelbase (mm) | 3225+1350 | |
| Front Overhang (mm) | 1500 | |
| Rear Overhang (mm) | 2615 | |
| Min. Clearance Above Ground (mm) | 314 | |
| Max. Traveling Speed (km/h) | 90 | |
| Min. Turning Diameter (m) | 17.3 | |
| Oil Consumption per 100 km (under limited conditions) |
≤25 | |
| Vehicle Configuration | Clutch | Dry Single Disc Clutch (φ430) |
| Gear Box | SINOTRUCK HW18709 | |
| Driving Type | 6*4 | |
| Steering Mechanism | ZF8098 | |
| Service Brake | Dual-circuit Air Brake | |
| Parking Braking | Spring-powered Air-cut-off Brake | |
| Auxiliary Brake | Engine Exhaust Brake | |
| Tyre | 12.00(R)-20 | |
| Engine Parameters | Model | WD615.95(E);WD615.96(E) |
| Type | In-line 6-cylinder, Water-cooled, Supercharged, Inter-cooled, Electric (Direct) Injection Diesel Engine | |
| Emission Standard | Euro III | |
| Discharge Capacity (L) | 9.726L | |
| Power (HP) | 290 HP(2200r/min) | |
| Max Torque | 1350 N.m(1100-1600r/min) | |
| Mixing Drum Parameters | Geometric Volume of Mixing Drum (m3) | 12.8 |
| Max. Mixing Cubage (m3) | 8-8.8 | |
| Feeding Speed | ≥3 | |
| Discharging Speed | ≥1.5 | |
| Leftover Rate | ≤0.5% | |
| Max Rotating Speed (r/min) | 14-16 | |
| Mixing Drum Obliquity (°) | 15 | |
| Max Mixing Drum Diameter (mm) | φ2162 | |
| Driving System | Speed Reducer | Italian BONFILI-577L |
| Hydraulic Pump | US EATON5423-518 | |
| Hydraulic Motor | US EATON4633-045 | |
| Radiator | German AKG with Vacuum Meter | |
| Water Supply System | Water Tank Capacity (L) | 260 |
| Water Supply Mode | Water Pump | |
