| Engine model | WD615.93C |
||
Engine Power |
290HP |
||
Displacement |
9726ml |
||
Fuel Type |
Diesel |
||
Emission standard |
Euro III |
||
Overall dimension (L*W*H) |
8375*2496*3950mm |
||
Wheelbase |
3200+1350mm |
||
Minimum turning circle |
20 |
||
Curb weight(kg) |
12300 |
||
Max speed(km/h) |
90 |
||
Fuel tank capacity(L) |
300 |
||
Fuel type |
Diesel |
||
Transmission model |
HW15710 |
||
Steering system |
ZF8098 |
||
Front axle |
HF9 |
||
Rear axle |
HC16 |
||
Tyre |
12.00-20(10+1spare) |
||
Brake system |
Service |
Dual circuit compressed air brake |
|
Parking |
Spring energy, compressed air operating on rear wheels |
||
Auxiliary |
Engine exhaust brake |
||
Electrical system |
Battery |
2X12V/165Ah |
|
Alternator |
28V-1500kw |
||
Starter |
7.5Kw/24V |
||
Cab |
HW76 cab, (one sleeper, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. |
||
Geometric Volume |
13.5m3 |
||
Agitating Capacity |
8m3 |
||
Drum rotating |
14° |
||
Agitator rotaion speed |
0-14r/min |
||
Feeding speed |
>3.5m3/min |
||
Water Tank Volume |
400L |
||
Discharge remain ratio |
<0.2% |
||
