| Vehicle parameters | |||
| Vehicle Model | HLW5317Z | ||
| Overall dimensions | 19000×2496×3785mm | Curb weight | 13560kg |
| Van dimensions | 9280×2362×2000mm /7000X2362X2000mm |
Loading capacity | 25T+20T |
| Chassis parameters | |||||
| Chassis model | ZZ1257V5841W | Chassis brand | SINOTRUK | ||
| Wheel base | 5825+1350mm | ||||
| Front/rear wheel track | 2022, 2041/1830,1830mm | Front/rear suspension | 1500/3288,3263mm | ||
| Approach/departure angle | 16/9° | Maximum speed | 102km/h | ||
| Chassis Manufacturer | China National Heavy Duty Truck Group Co.,Ltd | ||||
| Cab | Configuration | HW76 a row and a half deluxe cab(with sleeping berth), allowable 3 passengers | |||
| Color | White, other color is optional | ||||
| Engine | Model | D12.42-20 | |||
| Emission | Euro 2 | ||||
| Type | 6 cylinders, in-line, turbo inter-cooling | ||||
| Rated power | 420hp, rated power speed 1100rpm | ||||
| Displacement | 11596ml | ||||
| Max.torque | 1820N.m | ||||
| Bore x stroke | 126x155mm | ||||
| Manufacturer | China National Heavy Duty Truck Group Co.,Ltd | ||||
| Tire | Size | 12R20 | |||
| Number | 12 nos | ||||
| Clutch | φ430 diaphragm clutch | ||||
| Fuel tank | 400L iron oil tank | ||||
| Front axle | HF9 | ||||
| Rear axle | HC16 | ||||
| Drive form | 6x4 | ||||
| Suspension | Multi leaf springs | ||||
| Rated voltage | 24V, DC | ||||
| Transmissions | gearbox HW19710, 10 speed forward 2 reverse. | ||||
| Steering device | Power assisted steering ZF8118 | ||||
| Steering wheel | Left hand drive | ||||
| Selective configuration | |||||
| If there is a slight change in the chassis parameters above, please take the actual product as the standard | |||||
| Van body structure parameters | ||||
| Van dimensions | 9280×2362×2000mm 7000x2362x2000mm |
Loading capacity | 25T+20T | |
| Van material | Corrugated iron tile | Color and Logo | Optional | |
| Standard configuration | Chassis,sub frame,corrugated iron tile van body. | |||
| MOQ,payment terms,delivery terms,price | |
| MOQ | One unit |
| Payment terms | T/T 30% down payment, 70% balance after inspection before delivery |
| Inspection | Buyer's agent or third party inspection agency,the cost is paid by the buyer |
| Delivery term | 40 working days from down payment |
| Documentation | Maintenance manual |
| User manual | |
| Packing list | |
| Commercial invoice | |
| Spare parts list for purchase is optional | |
| Standard tools | With standard tools for chassis and van body structure |
| Packing | The main vehicle nude and covered with wax, attached parts and tools put into standard export box |
