ZHENGZHOU COOPER INDUSTRY CO., LTD., is one professional exporter of both brand new and used commercial vehicles and heavy equipment , as well as relevant spare parts in China.
For bus, like Coach Bus, City Bus, School Bus, coaster bus, the brands includes YUTONG, HIGER, KINGLONG, GOLDEN DRAGON, ZHONGTONG, TOYOTA, etc. For trucks, like dump truck, tractor truck, special purpose trucks, brands includes DONGFENG, SINOTRUCK HOWO, SHACMAN, BEIBEN, HUALING, etc.
With very good relationship with the Chinese main bus and truck manufacturers, and the professional team on sourcing of used/second hand bus & trucks and on export business, ZHENGZHOU COOPER INDUSTY CO., LTD. has grown quickly to a professional and famous exporter in commercial vehicles and heavy equipment, especially for the used/second units.
Looking to the future, ZHENGZHOU COOPER INDUSTY CO., LTD. will enhance core competitiveness of enterprises as a goal, enhance more professional skills to "MEET EVERY CUSTOMER’S REQUIREMENT" !
| Dimensions | |
| Overall dimension (mm) | 10650X2550X3550 |
| Wheelbase (mm) | 1850+4000+1350 |
| Min.ground clearance (mm) | 285 |
| Crew | 3 |
| Cabin | |
| Classic cabin | With air conditioner, mp3, radio, single sleeping bed |
| Dump box | |
| Deck dimension(mm) | 7500X2300X1500 |
| Volume(cube) | 25.9 |
| Bottom &Side | 8mm & 6mm |
| Hydraulic system | front lifting |
| Engine: CM6D18.385 31 385HP | |
| Type | Four-stroke, Water-cooled, Inline, Dry-liner, Direct-injection, Mechanic pump, EGR |
| Emission standard | Euro III |
| Max. Power | 283kW/1900rpm |
| Max. Torque | 1720N.m/1100~1500rpm |
| No. of cylinder | 6 |
| Bore x Stroke | 118*150 |
| Displacement | 9.84L |
| Controller type | Mechanical |
| Transmission | |
| Model | 9SDB2051A |
| Type | Mechanical(CAMC BRAND)with PTO |
| 9 forward shift, 1 backward shift | |
| Wheels & Tires | |
| Tires | 12.00R20, 12 tires & 1 spare tire |
| Axles | |
| Front | Stub Axle with Double T-cross Section Capacity: 2x 7,500KG |
| Rear | Double Reduction, final Drive Ratio: 5.263 Capacity: 2×16,000KG |
| Brake system | |
| Service | Full Air Brake, Dual circuit |
| Parking | Spring actuator at rear wheels |
| Auxiliary | Exhaust Brake |
| Fuel Tank | |
| Mounted on offside of the frame | |
| Capacity | 400L |
| Material | Steel |
| Steering | |
| Driving position | Right hand drive |
| Type | Power steering |
| Suspension | |
| Front suspension | tapered leaf spring 9 semi-elliptic leaf spring |
| Rear suspension | tapered leaf spring 12 semi-elliptic leaf spring |
