Specification | |
Model | ZZ3317N4267E1 |
Condition | USED |
Year | 2012 |
Drive | 8X4 |
Overall Dimensions(mm) | 10825x2550x3450 |
Wheelbase(mm) | 1800+4200+1350mm |
Engine | WP12.460E50 |
Gearbox | 12JSD200T |
Rear Axle Ratio | 3.727 |
Length(mm) | 6.905m |
Width(mm) | 2.5m |
Height(mm) | 3.97m |
Front Tread(mm) | 2041/2041mm |
Rear Tread(mm) | 1830/1830mm |
Curb weight(T) | 15.45t |
Total Weight(T) | 31 |
Max speed(km/h) | 110km/h |
Engine Brand | Wechai |
Number of cylinders | 6 |
Type of fuel | Diesel |
Displacement(L) | 9.726L |
Emission standard | Euro III |
Max Power | 375HP |
Maximum output Power | 276kw |
Torque(N.m) | 1560N.m |
Maximum torque speed | 1200-1500rpm |
Rated revolving speed | 2000rpm |
Buket Parameters(LxWxH)mm | 7800x2350x1500 |
Number of tyre | 12 |
Seat | 3 |
Shift way | Manual |
Shell | Aluminum alloy |
Tank Capacity | 300L |
Rear Axle bearable load | 17500kg |
Height of chassis above ground | 8+8/300mm |
Approach angle° | 14 |
Departure° | 21 |
Trade Terms:
Delivery time: Wihtin 5-8 working days after receipt of down payment.
Packing : Nude packing.
Shipment: By RO-RO or Bulk vessel .
Price validity: Within 30 days.
Payment terms: T/T before shipment.
Service we can provide: USED coaster bus, yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.
